Mobile Command Vehicle
Rolls a complete operations center to any location — self-contained, powered and ready to coordinate in minutes
Overview
The Mobile Command Vehicle houses a full command, control and communications suite inside a hardened, climate-controlled shelter body on a heavy-duty truck chassis. Multi-network gateways fuse HF, VHF, DMR, LTE and satellite links into one operating picture across four to six crew workstations, while bonded satellite and IP backhaul keep the platform connected off-grid. An on-board generator with UPS backup, a pneumatic mast and a networked video wall let a team stand up a working operations center anywhere, with no fixed installation.
The hardened shelter body carries four to six crew workstations, dual-position dispatch consoles and a networked video wall along the forward bulkhead, with rear and side access via lockable weatherproof doors and integrated fold-down steps.
Multi-network gateways bridge HF, VHF, DMR, LTE / cellular PTT and satellite links into a single dispatch picture, letting operators patch, cross-connect and record calls across otherwise incompatible networks from one console.
A pneumatic telescopic mast raises antennas and a pan-tilt-zoom camera to a working height of up to 12 m, extending line-of-sight radio reach and site coverage without repositioning the vehicle.
Backhaul combines auto-acquiring satellite terminals with bonded IP links, sustaining aggregate throughput of up to 100 Mbit/s so voice, video and data flow back to a parent operations center in real time.
On-board power is delivered by a 15 kVA diesel generator paired with a UPS bank that carries the full load for 30+ minutes, giving seamless changeover between generator, shore power and battery with no interruption to live operations.
A dual-zone HVAC system holds the interior at a stable working temperature across an ambient range of -30 to +60 C, protecting both crew and rack-mounted electronics through extended shifts in the field.
Gallery
In detail
Technical · 12 parameters
Specifications
Capabilities
- Self-contained mobile operations center on a hardened truck shelter
- Multi-network gateways fusing HF, VHF, DMR, LTE and satellite into one dispatch picture
- Bonded satellite and IP backhaul at up to 100 Mbit/s
- Four to six crew workstations, dual dispatch consoles and a networked video wall
- Pneumatic telescopic mast to 12 m for extended radio and camera reach
- 15 kVA on-board generator with UPS backup and seamless power changeover
- Dual-zone HVAC rated for -30 to +60 C operation
- Modular 19-inch racks for field-serviceable, upgradeable electronics
- Deploys to a working operations center in under 20 minutes
Where it operates
- On-site incident command for utilities, transport and critical-infrastructure operators
- Coordinating multi-team field operations across disparate radio and cellular networks
- Temporary operations center for large public events and planned site works
- Rapid restoration of command and communications after a network or facility outage
- Mobile coordination hub for remote construction, energy and industrial sites
- Backup operations center providing continuity when a fixed control room is unavailable
