Mobile Platforms
Deployable Comms Station
Stand up a full communications and monitoring site in minutes, anywhere the network needs to reach.
Overview
The Deployable Comms Station brings a complete communications and RF monitoring site to any location without civil works. A two-person crew levels the platform, raises a telescopic mast to lift antennas and sensors clear of clutter, and powers up radios, IP backhaul and control electronics housed in a hardened, climate-controlled enclosure. Multi-band coverage, wideband spectrum monitoring and a hybrid generator, mains and battery power train keep the site working for days, then it packs down and moves on.
A pneumatic telescopic mast elevates antennas and sensors up to 10 m above the platform, clearing local obstructions to extend line-of-sight coverage over a radius of several kilometres from a single site.
The hardened, climate-controlled enclosure integrates multi-band radios, IP backhaul, power conditioning and control electronics in one transportable footprint, holding an internal environment of +20 C across an outside range of -30 to +60 C.
A two-person crew completes deploy-and-operate setup in under 15 minutes with no fixed foundations or civil works, using integral levelling jacks and a guy-free self-supporting mast.
A hybrid power train sequences mains, a quiet diesel generator and a battery bank so the site runs continuously, delivering 12+ hours of autonomy on batteries alone before the generator restarts.
Wideband RF monitoring scans 20 MHz to 6 GHz to survey the local spectrum, verify channel availability and log interference before and during operation.
Multi-band radio payloads span VHF, UHF and broadband IP links, bridging voice and data traffic between field teams and the wider network over a single backhaul.
Gallery
In detail
Technical · 12 parameters
Specifications
Capabilities
- Pneumatic telescopic mast elevating antennas and sensors up to 10 m
- Rapid deploy-and-operate setup in under 15 minutes with a two-person crew
- Hardened, climate-controlled enclosure rated IP66 for all-weather operation
- Integrated multi-band radios, IP backhaul and control electronics
- Wideband RF monitoring across 20 MHz to 6 GHz
- Hybrid mains, generator and battery power with 12+ hours of battery autonomy
- Self-supporting guy-free mast requiring no fixed foundations
- Local control terminal with remote status reporting over IP
- Transportable on a light trailer or standard 4x4 flatbed
Where it operates
- Temporary communications coverage for construction sites, festivals and outdoor events
- Rapid restoration of connectivity after a network outage or natural disaster
- Extended-range spectrum monitoring and interference surveys for utilities and operators
- Coverage extension for remote industrial sites, mines and pipelines beyond fixed infrastructure
- Seasonal or project-based sites that need a full communications hub without permanent build-out
- Rapidly relocatable backhaul relay bridging field teams to a central operations centre
