Anti-Drone Vehicle Heavy
The Anti-Drone Command and Control Shelter mounted on a 4x4 truck chassis, giving the same radar + RF detection and 70 MHz - 6…
Overview
The Anti-Drone Command and Control Shelter mounted on a 4x4 truck chassis, giving the same radar + RF detection and 70 MHz - 6 GHz jamming capability as the static shelter but able to self-deploy. Radar detection 5 km (RCS 0.01 m2), spectrum detection 15 km against 30 targets, jamming to 5 km, response time under 4 seconds, with electric masts and electronic outriggers.
This configuration takes the anti-drone shelter and integrates it onto a light 4x4 truck so the complete detection, jamming, decoy and command suite can move with the force. It integrates radio detection, radar detection, spectrum jamming and navigation decoy so that response time is less than 4 seconds, achieving "jamming upon discovery" of UAV targets.
Real-time acquisition and processing of UAV target information gives a fully visible map-background display of detection, identification, tracking and attacking. Interference is full-band software defined - 70 MHz to 6 GHz SDR broadband write-frequency interference counters more than 98% of civil and customized band UAV communication links.
It supports radio detection of 30 drones at the same time while the radar detects and tracks more than 100 targets simultaneously, dealing with UAV swarms. Radar, spectrum detection and spectrum jamming antennas are mounted on automatic lifting rods, the system is EMC designed and the body is a selected 40 dB shelter.
Compared with the static shelter, the interconnection architecture adds a multi-band radio in place of the VHF-only set, an integrated control device, an electric suppressing device and electronic outriggers for stabilising the vehicle when the masts are raised.
Provide a drive-anywhere counter-drone station with full radar-plus-RF detection and a manned command cabin, without the site preparation a static shelter needs.
Technical · 22 parameters
Specifications
Key features
- Integrated detection & jamming — Radio, radar, spectrum jamming and navigation decoy integrated; response time under 4 s.
- Fully visible — Real-time processing with map-background display of the whole engagement.
- Full band software defined interference — 70 MHz - 6 GHz SDR broadband interference covering more than 98% of civil and customized band UAV links.
- Batch target tracking — 30 simultaneous radio detections; radar tracks more than 100 targets at once.
- System integration — Antennas on automatic lifting rods; EMC designed; selected 40 dB shelter.
Where it operates
- Deployable site protection — Drives to a site, raises masts on electronic outriggers and establishes a low-altitude protection area.
- Automatic jamming upon discovery — Detection to countermeasure in under 4 seconds using full-band SDR interference.
- Radar and RF fused detection — Low-altitude surveillance radar plus omnidirectional RF detection feed one map picture.
- GNSS denial / decoy — The "coagulation defense system" / "deceiving the defense system" element spoofs the drone's satellite navigation.
